Technical Data
| Condensate Treatment | Optional |
|---|---|
| Particulate Treatment | – |
| Air purity class (ISO 8573-1) | X-X-0 |
| Voltage (V) | 400,00 |
| Frequency (Hz) | 50,00 |
| Nominal rating (kW) | 4,00 |
| Nominal rating (HP) | 5,50 |
| Rotation speed (rpm) | 1.400,00 |
| Absorption (A) | 8,00 |
| Number of cylinders | 4 |
| Air intake (L/min) | 660,00 |
| Air Delivery (L/min @5 bar) | 400,00 |
| Air Delivery (L/min @8 bar) | 370,00 |
| Maximum pressure (bar) | 10,00 |
| Noise level (3,00m @ 5,00 bar (dB(A))) | 74,00 |
| Duty cycle | S1 100% |
| Tank Coating | Epossidica (interno/esterno) |
| Tank capacity (lt) | 270,00 |
| First Maintenance (hours) | 3000 |
| Hour Meter | Incluso |
| Tank Automatic Drain kit | Optional |
Product dimensions
| Dimensions (cm) – LxWxH | Weight (Kg) | Pieces |
|---|---|---|
| 158,2x50x92,9 | 131 | 1 |
Single piece packaging dimensions
| Dimensions (cm) – LxWxH | Weight (Kg) | Pieces |
|---|---|---|
| 170x65x110 | 156 | 1 |
Full pallet packaging dimensions
| Dimensions (cm) – LxWxH | Weight (Kg) | Pieces |
|---|---|---|
| 170x65x110 | 156 | 1 |
